XG Series User's Guide Chapter 5 Command Reference
LAN Information Settings 210
5.5.5.2 oob ip route
Function Set the IPv4static route information
Available Model XG2600
Syntax oob ip route
Options
• Static route information definition number
Specify a static route information definition number with a decimal value.
Specify a destination network with a combination of the IPv4 address and the number
of mask bits. For the mask value, specify successive 1s following the most significant
bit (MSB). The available description format is as follows:
- IPv4 address/number of mask bits (Example: 192.168.1.0/24)
- IPv4 address/mask value (Example: 192.168.1.0/255.255.255.0)
• default
Specify default when the default route is set as a destination network.
It’s same as specifying 0.0.0.0/0(0.0.0.0/0.0.0.0)
• IPv4 address of next hop router
Specify the IPv4 address of the next hop router
• Priority
Specify the static route information priority with a decimal value from 1 to 254.
A smallr value has a higher priority.
The default is 1.
Use Mode Configuration mode (admin class)
Explanation Set the IPv4 static route information
Caution When the same destination as static route is set, be careful about the following.
• Multiple default routes can not be cofigured with the same priority.
Default N/A
Range Model
0 to 199 XG2600
Max definition number Model
200 XG2600
