XG Series User's Guide Chapter 5 Command Reference
Bridge Counter, Log, Statistics, and Status Display and Clear Operation
Commands
467
5.28.3.2 show spanning-tree instance
Function Display the spanning tree information.
Available Model XG0224 / XG0448 / XG2600
Syntax show spanning-tree instance [detail]
Options
Display the spanning tree information of the specified instance only.
detail
Display the spanning tree information of the specified instance in detail.
Use Mode Operation mode (user class/admin class)
Configuration mode (admin class)
Explanation Display the status of the MSTP spanning tree function.
Execution Example
Display of spanning tree information of instance 0
(To be continued)
# show spanning-tree instance 0
MSTP Configuration Information
Region Name : region1 Revision Level : 0
--------------------- ------------------
(1) (2)
Instance ID 0
-------------
(3)
Vlans 20-30
------------------------
(4)
Root ID Priority 32768 ---(5)
Address 00:00:e2:08:57:89 ---(6)
Cost 200000 ---(7)
Port 1 (eth1) ---(8)
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
---------------- -------------- --------------------
(9) (10) (11)
Remaining Hops 20
-----------------
(12)
Bridge ID Priority 32768 ---(13)
Address 00:0b:5d:89:00:aa ---(14)
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
---------------- -------------- --------------------
(15) (16) (17)
Hop count 20
-------------
(18)
BPDU Mode off
-------------
(19)
STP Mode mstp
-------------
(20)
