XG Series User's Guide
Chapter 5 Command Reference
LLDP Counter, Log, Statistics, and Status Display and Clear Operation
Commands
481
Execution Example
(To be continued)
# show lldp
Send Interval Time
: 30 seconds
---(1)
Send Hold Count
: 4 times
---(2)
Send Delay
: 2 seconds
---(3)
Reinit Delay
: 2 seconds
---(4)
Notification Interval Time
: 5 seconds
---(5)
Port Mode
Size
Info P N D C A
P p N I
M P L F
T
---- -------
----
--------------
-------
------- -
(6) (7)
(8)
(9)
(10)
(11)
(12)
1
enable 274
P N D C A
P p N I
M P L F
-
2 receive
0
8
send
179
P - D C A
P p N -
M - - -
-
Entry:3 ---(30)
#
# show lldp port 1,8 detail
Send Interval Time
: 30 seconds
---(1)
Send Hold Count
: 4 times
---(2)
Send Delay
: 2 seconds
---(3)
Reinit Delay
: 2 seconds
---(4)
Notification Interval Time
: 5 seconds
---(5)
[PORT 1]
---(6)
Configuration Mode
: enable
---(7)
Send LLDPDU size
: 274 octets
---(8)
Chassis ID
: subtype=4(MAC) info=00:0b:5d:fd:05:b2
---(13)
Port ID
: subtype=5(ifName) info="1"
---(14)
Time To Live(TTL)
: 120 seconds
---(15)
Port Description
: info="EthernetPort(ether1)"
---(16)
System Name
: info=""
---(17)
System Description
: info="'SBAX2' '1.2 V01.00' 'Wed Feb 13 15:23:07
JST
2008'"
---(18)
System Capabilities
: info=Bridge,Router
---(19)
enabled=Bridge
Management Address
: address subtype=1(IPv4) info=192.168.2.1 ---(20)
interface number subtype=2(ifIndex) info=3
oid=""
Management Address
: address subtype=6(MAC) info=00:0b:5d:fd:05:b3
interface number subtype=2(ifIndex) info=7001
oid=""
IEEE802.1
Port VLAN ID
: PVID=10
---(21)
Port And Protocol VLAN ID
: flags=supported,enabled
---(22)
PPVID=20
Port And Protocol VLAN ID : flags=supported,enabled
PPVID=21
VLAN Name
: VID=10
---(23)
name="portvlan10"
VLAN Name
: VID=20
name="protocolvlan20"
VLAN Name
: VID=21
name="protocolvlan21"
VLAN Name
: VID=30
name="taggedvlan30"
IEEE802.3
MAC/PHY Configuration/Status : support/status=supported,enabled ---(25)
capability=1(10BASE-T half duplex mode),
2(10BASE-T full duplex mode),
4(100BASE-TX half duplex mode),
5(100BASE-TX full duplex mode),
8(PAUSE for full-duplex links),
11(Asymmetric and Symmetric PAUSE
for full-duplex links),
15(1000BASE-T full duplex mode)
type=16(100BASE-TX full duplex mode)
Power Via MDI
: support=PSE,not supported
---(26)
Link Aggregation
: status=capable,not in aggregation
---(27)
Maximum Frame Size
: size=9216
---(28)
SNMP Notification Trap Send : disable
---(29)
