XG Series User's Guide Chapter 5 Command Reference
Port Information Settings 140
The following is the number of masks for ACL..
The following is the number of masks for "vlan protocol" command.
• Upper limit based on "actions"
16 actions for the entire device.
Up to16 actions can be set for the entire device, including the
"ether qos aclmap" , "vlan
qos aclmap" , "lan ip dscp" , "vlan protocol" commands.
The priority for each command is as follows.
1) "vlan protocol" commands
2) "ether qos aclmap" command
A smaller Ethernet port number has a higher priority among Ethernet ports.
3) "vlan qos aclmap" command
A smaller VLAN ID has a higher priority among VLANs.
4) "lan ip dscp" command
A smaller lan definition number has a higher priority among lans.
The following commands spend 1 action regardless of multiple use.
- vlan protocol ipv4
- vlan protocol ipv6
ACL number of masks
"acl mac"
define LSAP of llc 3
not define LSAP of llc 1
"acl vlan" 1
not define src IP address
not define tos/dscp value 1
not define tos/dscp value 3
define src IP address
not define dst IP address 1
define dst IP address
use same netmask for src and dst IP address
not define tos/dscp value 1
not define tos/dscp value 3
use different netmask for src and dst IP address 3
"vlan protocol" definition number of masks
define vlan protocol ipv4 3
define vlan protocol ipv6 1
define vlan protocol ether 1
define vlan protocol llc 1
