XG Series User's Guide Chapter 5 Command Reference
ACL Information Settings 234
• Messages other than those above
Specify the target MAC address. Specify the source MAC address for ACL in the
xx:xx:xx:xx:xx:xx format, where "xx" is a 2-digit hexadecimal value.
• llc
Specify it when targeting the LLC-format frame in which the value of matches
LSAP. In , specify a hexadecimal value from 0 to ffff.
To target all LLC-format frames, specify "any" in .
• ether
Specify it when targeting the Ethernet-format frame in which the value of
matches the type. In , specify a hexadecimal value from 5dd to ffff.
To target all Ethernet-format frames, specify "any" in .
• any
Specify it when targeting all frames. is not necessary.
Use Mode Configuration mode (admin class)
Explanation Specify the etherframe pattern in the ACL definition.
Default Any etherframe pattern can be specified in the ACL definition.
5.12.1.2 acl vlan
Function Set the definition of the ACL VLAN.
Available Model XG0224 / XG0448 / XG2600
Syntax acl vlan
Options
• ACL definition number
Specify an ACL definition serial number with a decimal value.
Specify the source VID address for ACL.
• any
Specify when targeting all VID addresses.
• Other than those above
Specify the target VID. The allowable range of VID addresses for ACL is 1 to 4094.
Specify COS for ACL.
• any
Specify it when targeting all COS.
• Other than those above
Specify the target COS. The allowable range of COS for ACL is 0 to 7.
Use Mode Configuration mode (admin class)
Explanation Specify VLAN in the ACL definition.
Default Any VLAN ID can be specified in the ACL definition.
