XG Series User's Guide Chapter 5 Command Reference
LAN Information Settings 196
- For ACL to set ICMP
Result of multiplication between the number of ICMP TYPEs and the number of
ICMP CODEs for ICMP
- For ACL not to set TCP, UDP, or ICMP
1
You can expand the upper limit to use "resource filter distribution" command and change
resource distribution.
Note 4.
Up to 700 commands can be set for the entire device, including the definitions which refer
to ACL such as
"ether macfilter" , "ether qos aclmap" , "vlan macfilter" , "vlan ip6filter" ,
"vlan qos aclmap" , "vlan ip6qos aclmap" , "lan ip filter" , "lan ip dscp" , "lan ip6 filter" , "lan
ip6 dscp" and "serverinfo filter" commands.
Default It is assumed that DSCP value rewriting is not performed.
5.5.1.7 lan ip dscp move
Function Change the priority of DSCP value rewriting conditions.
Available Model XG0224 / XG0448 / XG2600
Syntax lan [] ip dscp move
Options
• lan definition number
Specify a lan definition serial number with a decimal value.
The default is 0.
• Target DSCP value rewriting definition number
Specify a DSCP value rewriting definition number before the priority was changed.
• Destination DSCP value rewriting definition number
Specify a new priority for with a decimal value.
If any definition with the same definition number exists, it will be inserted before the
existing one.
Use Mode Configuration mode (admin class)
Explanation Change the priority of DSCP value rewriting conditions.
Range Model
0 to 511 XG0224 / XG0448
0 to 63 XG2600
