XG Series User's Guide Chapter 5 Command Reference
Port Information Settings 148
5.1.8.2 ether icmpwatch interval
Function Set various types of "ether" L3 monitoring intervals.
Available Model XG0224 / XG0448 / XG2600
Syntax ether icmpwatch interval []
Options
• ether port number
Set a port number to use with a decimal value.
When setting multiple port numbers, separate them with commas (,).
When setting sequential numbers, separate them with hyphens (-). (Example: "1-8")
• Transmission interval of normal ICMP ECHO packets
Specify the transmission interval of normal ICMP ECHO packets to be within the range
of 1 to 60 seconds (or 1 minute).
The unit shall be m (minute) or s (second).
• Monitoring timeout
Specify the monitoring timeout period as between 5 to 180 seconds (or 3 minutes). If
the time exceeds, the monitoring is considered as failed.
The unit should be in m (minute) or s (second).
• Retransmission interval of ICMP ECHO packets
Specify the retransmission interval of ICMP ECHO packets between 1 to -1
seconds if the normal ICMP ECHO packet transmission is not acknowledged.
The unit should be in m (minute) or s (second).
The default is 1s.
Use Mode Configuration mode (admin class)
Explanation Set the operation information for destination monitoring.
The destination is monitored in when the response of ICMP ECHO packet is
normally received.
If the response to ICMP ECHO packet is not received, the packet is resent by the .
If no response is returned within the time period specified in the , an error is
detected assuming that any fault occurs and the Ethernet port specified in the
goes offline.
Caution If ports go offline, release them with the "online" command.
Default It is assumed that the 10-second transmission interval during normal communication, the
5-second timeout for monitoring, and the 1-second retransmission interval have been
specified.
ether icmpwatch interval 10s 5s 1s
