XG Series User's Guide

Chapter 5 Command Reference

Bridge Counter, Log, Statistics, and Status Display and Clear Operation

Commands

473

(Continued)

Interface name and port status

One of the following is displayed for the port status.
Disabled

: The STP is disabled.

Discarding

: The port is in the discarding state (it is displayed only when

RSTP or MSTP is active).

Blocking

: The port is in the blocking state.

Listening

: The port is in the listening state.

Learning

: The port is in the learning state.

Forwarding

: The port is in the forwarding state.

STP version of port

One of the following is displayed for the STP version.
- (OFF)

: STP unused port

0 (STP)

: 802.1d STP

2 (RSTP)

: 802.1w RSTP

3 (MSTP)

: 802.1s MSTP

Port path cost

The path cost of the relevant port is displayed.

Port priority

The priority of the relevant port is displayed.

Port ID

The port ID (the port priority and port number) is displayed.

BPDU statistics:

Config BPDU: sent 141, sent error 0

-------- ------------

(16) (17)

received 138, discarded 1

------------ -----------

(18) (19)

TCN BPDU: sent 0, sent error 0

------ ------------

(20) (21)

received 0, discarded 0

---------- -----------

(22) (23)

Other error: bad protocol 0, bad version 0

-------------- -------------

(24) (25)

bad BPDU type 0

---------------

(26)

Other statistics:

changed to forwarding state 1

---

(32)

eth2 is Forwarding Port Version 3(MSTP) STP-Compatible(-) Boundary(-)

Port path cost 20000(auto), Port priority 128, Port Identifier 128.2

Port role is Designated

Designated root has priority 0, address 00:0b:5d:89:00:bb

Designated bridge has priority 0, address 00:0b:5d:89:00:bb

Designated port is 128.2, Designated path cost 0

Port info type is Mine

Remaining Hops 20

This port is internal region
