XG Series User's Guide Chapter 5 Command Reference
Port Information Settings 138
• Replacing value
If "cos" is selected in :
-
Set the replaced "cos" value with a decimal value from 0 to 7.
- tos
Replace the "cos" value with the "ip precedence" value in the packet.
If "dscp" is selected in :
-
Set the replaced "dscp" value with a decimal value from 0 to 63.
If "tos" is selected in :
-
Set the replaced "ip precedence" value with a decimal value from 0 to 7.
- cos
Replace the "ip precedence" value with the "cos" value.
If "queue" is selected in :
-
Specify a queue number of the output port to be used.
A larger value indicates a queue with a higher output priority.
• ACL definition number
Specify the ACL definition number of the access control list where the packet pattern to
configure QoS conversion has been defined.
Use Mode Configuration mode (admin class)
Explanation Set the QoS (quality of service) of each Ethernet port.
For the ingress packets that match the "acl mac", "acl vlan", "acl ip", "acl icmp", "acl tcp",
or "acl udp" definitions of the access control list which has been specified by , the
QoS processing is executed in the way as specified by .
Caution
Note 1.
If none of "acl mac", "acl vlan" and "acl ip" definitions exist on the access control list
which has been specified by or if the access control list specified by does not
exist, the packets are not filtered.
[XG2600]
Note 2.
If a queue is selected by and if this queue has not been associated with the cos
value by the
"ether qos prioritymap" command, the QoS processing is not executed.
Note 3.
"acl mac llc" definitions can not filter llc frames with the VLAN tag.
Range Model
0 to 7 XG0224 / XG0448 / XG2600
