XG Series User's Guide Chapter 5 Command Reference
LAN Information Settings 204
5.5.2.8 lan ip6 dscp
Function Set DSCP value rewrite condition
Available Model XG0224 / XG0448
Syntax lan [] ip6 dscp acl
Options
• lan definition number
Specify lan definition number with a decimal value
• DSCP rewrite definition number
Specify priority of DSCP rewrite condition with a decimal value.
• ACL definition number
Specify ACL definition number with a decimal value
- ip6
If ip6 value is not configured, that filter definition is ignored
- tcp
This is enabled when ip6 value is 6
- udp
This is enabled when ip6 value is 17
- icmp
This is enabled when ip6 value is 58
• DSCP value
Specify Rewrite DSCP value with a decimal value from 0 to 63
Use Mode Configuration mode (admin class)
Explanation Set DSCP value rewrite condition
Caution
Note1.
If none of "acl ip6" definition exist on the access control list which has been specified by
or if the access control list specified by does not exist, the QoS processing is
not applied to those packets.
Note2.
If a queue is selected in and if this queue has not been associated with the
priority by the
"qos cosmap" command, the QoS processing is not executed.
Note 3.
This command is unavailable if the allowable upper limit for the device is exceeded.
The allowable upper limits are as follows.
• Upper limit based on "commands"
128 commands for the entire device.
Up to 128 commands can be set for the entire device, including the
"vlan ip6qos
aclmap" and "lan ip6 dscp" commands.
Range Model
0 to 511 XG0224 / XG0448
