Rockwell Automation Publication 193-UM002I-EN-P - December 2011 9
Preface
Manual Objectives The purpose of this manual is to provide you with the necessary information to
apply the E3 Overload Relay with DeviceNet communications. Described in this
manual are methods for installing, configuring, and troubleshooting.
Who Should Use This
Manual This manual is intended for qualified personnel responsible for setting up and
servicing these devices. You must have previous experience with and a basic
understanding of communications technology, configuration procedures,
required equipment, and safety precautions.
To make efficient use of the E3 Overload Relay, you must be able to program and
operate devices with communications and have a basic understanding of the E3
Overload Relay’s parameter settings and functions. You should also understand
DeviceNet network operations, including how slave devices operate on the
network and communicate with a DeviceNet master.
Vocabulary In this manual, we refer to the:
• E3 Overload Relay as it applies to both the E3 and E3 Plus Overload
Relays.
• E3 Plus Overload Relay when features and/or functions apply specifically
to it.
Conventions Parameter names are shown in italic typeface.
E3 refers to the overload relays E3 and E3 Plus. “E3” is the standard version. “E3
Plus” is the enhanced version.
Reference Manuals For SLC 500 and 1747-SDN information:
• DeviceNet Scanner Module Installation Instructions Publication
1747-IN058E-EN-P
• DeviceNet Scanner Module User Manual Publication
1747-UM655B-EN-P
For PLC5 and 1771-SDN information:
• DeviceNet Scanner Module Installation Instructions Publication 1771-5.14
• DeviceNet Scanner Module Configuration Manual Publication
1771-6.5.118
For MicroLogix/CompactLogic and 1769-ADN information:
IMPORTANT Read this manual in its entirety before installing, operating,
servicing, or initializing the E3 Overload Relay.
