Rockwell Automation Publication 193-UM002I-EN-P - December 2011

115

Programmable Parameters Chapter 5

Table 47 - Warning Enable Bit Function Detail

Table 48 - Overload Warning Level Parameter Detail

Table 49 - Phase Loss Parameters Detail

Bit

Function

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

X

Overload

X

Ground Fault (E3 Plus)

X

Jam

X

Underload

X

PTC (E3 Plus)

X

Current Imbalance

X

Comm Fault

X

Comm Idle

X

PM #Starts — Series C & Later

X

PM Oper. Hours — Series C & Later

OL WARN LEVEL

This parameter sets the overload warning

level.

Parameter Number

32

Access Rule

Get/Set

Data Type

USINT

Object Mapping

2C

hex

-1-132

Group

Advanced Setup

Units

% Thermal Utilization

Minimum Value

0

Maximum Value

100

Default Value

85

PL INHIBIT TIME

This parameter defines the amount of time

for which phase loss detection is inhibited

during a motor starting sequence.

Parameter Number

33

Access Rule

Get/Set

Data Type

USINT

Object Mapping

2C

hex

-1-133

Group

Advanced Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

0

PL TRIP DELAY

This parameter allows the installer to

program a time duration for which a phase

loss condition must exist prior to the device

tripping.

Parameter Number

34

Access Rule

Get/Set

Data Type

USINT

Object Mapping

2C

hex

-1-134

Group

Advanced Setup

Units

Seconds

Minimum Value

0.1

Maximum Value

25.0

Default Value

1.0
