138 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 6 Monitoring Parameters
Monitor Group
L1 CURRENT
This parameter provides the L1 phase
current
measurement in amperes.
Parameter Number 1
Access Rule Get
Data Type INT
Object Mapping 2C
hex
-1-231
2C
hex
-1-8
2C
hex
-1-227
Group Monitor
Units Amps
Minimum Value See Table 1:
Maximum Value See Table 1:
Default Value None
L2 CURRENT
This parameter provides the L2 phase
current
measurement in amperes.
Parameter Number 2
Access Rule Get
Data Type INT
Object Mapping 2C
hex
-1-232
2C
hex
-1-9
2C
hex
-1-228
Group Monitor
Units Amps
Minimum Value See Table 1:
Maximum Value See Table 1:
Default Value None
L3 CURRENT
This parameter provides the L3 phase
current
measurement in amperes.
Parameter Number 3
Access Rule Get
Data Type INT
Object Mapping 2C
hex
-1-233
2C
hex
-1-10
2C
hex
-1-229
Group Monitor
Units Amps
Minimum Value See Table 1:
Maximum Value See Table 1:
Default Value None
AVERAGE CURRENT
This parameter provides the average
current measurement in amperes.
Parameter Number 4
Access Rule Get
Data Type INT
Object Mapping 2C
hex
-1-230
2C
hex
-1-5
2C
hex
-1-226
Group Monitor
Units Amps
Minimum Value See Table 1:
Maximum Value See Table 1:
Default Value None
L1 %FLA
This parameter provides the L1 phase
current
measurement as a percentage of the
motor’s full load current rating (Parameter
28, FLA Setting).
Parameter Number 5
Access Rule Get
Data Type UINT
Object Mapping 2C
hex
-1-105
Group Monitor
Units % FLA
Minimum Value 0
Maximum Value 1000
Default Value None
