Table 56 - Input Parameters Detail
IN1 ASSIGNMENT
This parameter allows the user to assign a
specific function to the discrete IN1 input.
Parameter Number 83
Access Rule Get/Set
Data Type USINT
Object Mapping 29
hex
-1-177
Group Advanced Setup
Units —
Minimum Value 0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2-Speed
Maximum Value 4 = Force Snapshot ➊
Default Value 0
IN2 ASSIGNMENT
This parameter allows the user to assign a
specific function to the discrete IN2 input.
Parameter Number 84
Access Rule Get/Set
Data Type USINT
Object Mapping 29
hex
-1-178
Group Advanced Setup
Units —
Minimum Value 0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2-Speed
Maximum Value 4 = Force Snapshot ➊
Default Value 0
IN3 ASSIGNMENT (E3 Plus)
This parameter allows the user to assign a
specific function to the discrete IN3 input.
Parameter Number 85
Access Rule Get/Set
Data Type USINT
Object Mapping 29
hex
-1-179
Group Advanced Setup
Units —
Minimum Value 0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2-Speed
Maximum Value 4 = Force Snapshot ➊
Default Value 0
IN4 ASSIGNMENT (E3 Plus)
This parameter allows the user to assign a
specific function to the discrete IN4 input.
Parameter Number 86
Access Rule Get/Set
Data Type USINT
Object Mapping 29
hex
-1-180
Group Advanced Setup
Units --
Minimum Value 0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2-Speed
Maximum Value 4 = Force Snapshot ➊
Default Value 0
➊ Available in FRN 5.00 and higher
