Rockwell Automation Publication 193-UM002I-EN-P - December 2011

167

Power Parameters Chapter 8

kVARh Net 10E6

This parameter provides a component of
total reactive energy net (kVARh).
Multiply this value by 10

6

and add to the

other kVARh net parameters.

Represents XXX,000,000.000

Parameter Number

201

Access Rule

Get

Data Type

INT

Object Mapping

0Fhex-C9-01

Group

Power Monitor

Units

Minimum Value

-32768

Maximum Value

32767

Default Value

kVARh Net 10E3

This parameter provides a component of
total reactive energy net (kVARh).
Multiply this value by 10

3

and add to the

other kVARh net parameters.

Represents 000,XXX,000.000

Parameter Number

202

Access Rule

Get

Data Type

INT

Object Mapping

0Fhex-CA-01

Group

Power Monitor

Units

Minimum Value

-999

Maximum Value

999

Default Value

kVARh Net 10E0

This parameter provides a component of
total reactive energy net (kVARh).
Multiply this value by 10

0

and add to the

other kVARh net parameters.

Represents 000,000,XXX.000

Parameter Number

203

Access Rule

Get

Data Type

INT

Object Mapping

0Fhex-CB-01

Group

Power Monitor

Units

Minimum Value

-999

Maximum Value

999

Default Value

kVARh Net 10E-3

This parameter provides a component of
total reactive energy net (kVARh).
Multiply this value by 10

-3

and add to the

other kVARh net parameters.

Represents 000,000,000.XXX

Parameter Number

204

Access Rule

Get

Data Type

INT

Object Mapping

0Fhex-CC-01

Group

Power Monitor

Units

Minimum Value

-999

Maximum Value

999

Default Value

kVAh Net 10E6

This parameter provides a component of
total apparent energy (kVAh). Multiply
this value by 10

6

and add to the other

kVAh parameters.

Represents XXX,000,000.000

Parameter Number

205

Access Rule

Get

Data Type

INT

Object Mapping

0Fhex-CD-01

Group

Power Monitor

Units

Minimum Value

-32768

Maximum Value

32767

Default Value
