106 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 5 Programmable Parameters
Additional information on select parameter groups may be found in the
upcoming chapters, as listed below.
Table 27 - Monitor Group
Table 28 - Overload Setup
• Monitor Group, Chapter 6
• Voltage Setup, Chapter 7
• Power Setup, Chapter 8
• Trip History, Chapter 9
• Snapshot Group, Chapter 9
Parameter Number Description Parameter Number Description
1 L1 Current 17 Trip Log 1
2 L2 Current 18 Trip Log 2
3 L3 Current 19 Trip Log 3
4 Average Current 20 Trip Log 4
5 L1 % FLA 21 Device Status
6 L2 % FLA 22 Firmware
7 L3 % FLA 23 Device Configuration
8 Average % FLA 90 Warning Log 0 ➊
9 % Therm Utilized 91 Warning Log 1 ➊
10 GF Current 92 Warning Log 2 ➊
11 Current Imbalance 93 Warning Log 3 ➊
12 OL Time to Trip 94 Warning Log 4 ➊
13 OL Time to Reset 95 Elapsed Time ➊
14 Trip Status 96 Starts Counter ➊
15 Warning Status 97 Starts Available ➊
16 Trip Log 0 98 Time to Start ➊
➊ Series C (FRN 4.00 and higher)
Parameter Number Description Parameter Number Description
27 Single/Three Phase 30 OL /PTC Reset Mode
28 FLA Setting 31 OL Reset Ratio
29 Trip Class 78 CT Ratio
