Chapter 8 Power Parameters

UW Inhibit Time

This parameter defines the amount of
time for which an under real power (kW)
detection is inhibited during a motor
starting sequence.

Parameter Number

241

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-F1-01

Group

Power Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

10

UW Trip Delay

This parameter allows the installer to
program a time duration for which an
under real power (kW) condition must
exist prior to the device tripping.

Parameter Number

242

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-F2-01

Group

Power Setup

Units

Seconds

Minimum Value

0.1

Maximum Value

25.0

Default Value

1.0

UW Trip Level

This parameter sets the under real power
(kW) trip level.

Parameter Number

243

Access Rule

Get/Set

Data Type

INT

Object Mapping

0Fhex-F3-01

Group

Power Setup

Units

kW

Minimum Value

0

Maximum Value

32767

Default Value

UV Warn Level

This parameter sets the under real power
(kW) warning level.

Parameter Number

244

Access Rule

Get/Set

Data Type

INT

Object Mapping

0Fhex-F4-01

Group

Power Setup

Units

kW

Minimum Value

0

Maximum Value

32767

Default Value

OW Inhibit Time

This parameter defines the amount of
time for which an over real power (kW)
detection is inhibited during a motor
starting sequence.

Parameter Number

245

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-F5-01

Group

Power Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

10
