252 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Appendix B DeviceNet™ Information
Table 120 - Overload Object Instance Attributes
Attribute
ID Access
Rule Name Data
Type Value Default
3 Get/Set TripFLCSet INT See Table 32: 1.0
4 Get/Set TripClass USINT 5…30 10
5 Get AvgCurrent INT See Table 34: 0.0
6 Get %PhImbal USINT 0…200% 0
7 Get %Thermal USINT 0…100% 0
8 Get CurrentL1 INT See Table 34: 0.0
9 Get CurrentL2 INT See Table 34: 0.0
10 Get CurrentL3 INT See Table 34: 0.0
11 Get Ground Current INT 0.0…12.7 A 0.0
The following attributes are all vendor specific.
101 Get L1 Current INT
These attributes exist
only for current ranges
that report 1 or 2
decimal places current
resolution
102 Get L2 Current INT
103 Get L3 Current INT
104 Get Average Current INT
105 Get L1%FLA UINT 0…1000 %FLA 0
106 Get L2%FLA UINT 0…1000 %FLA 0
107 Get L3%FLA UINT 0…1000 %FLA 0
108 Get Average %FLA UINT 0…1000 %FLA 0
109 Get %Therm Utilized USINT 0…100% 0
110 Get GF Current INT 0.00...12.75 A 0.0
111 Get Current Imbal USINT 0…200% 0
112 Get Time to Trip UINT 0…9999 s 0
113 Get Time to Reset UINT 0…9999 s 0
127 Get/Set Single/Three Ph BOOL
0 = Single
1 = Three Phase
1
128 Get/Set FLA Setting UINT
This attribute exists
only for current ranges
that report 1 or 2
decimal places current
resolution
Current range
dependent
129 Get/Set Trip Class USINT 5…30 10
132 Get/Set OL Warn Level USINT 0…100 %TCU 85
133 Get/Set PL Inhibit Time USINT 0…250 seconds 0
134 Get/Set PL Trip Delay USINT 0.1…25.0 seconds 1.0
135 Get/Set GF Inhibit Time USINT 0…250 seconds 0
136 Get/Set GF Trip Delay USINT 0.1…25.0 seconds 0.5
137 Get/Set GF Trip Level USINT 1.0…5.0 A 2.5
138 Get/Set GF Warn Level USINT 1.0…5.0 A 2.0
139 Get/Set Stall Enabld Time USINT 0…250 seconds 0
140 Get/Set Stall Trip Level UINT 100…600 600
141 Get/Set Jam Inhibit Time USINT 0…250 seconds 0
142 Get/Set Jam Trip Delay USINT 0.1…25.0 seconds 5.0
