PW Trip Status
This parameter provides power based
trip identification as outlined in the table
below:
1 = Trip
0 = No TrIp
Parameter Number 227
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-E3-01
Group Power Monitor
Units —
Minimum Value —
Maximum Value —
Default Value —
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Under Real Pwr
X Over Real Pwr
X Under Con kVAR
X Over Con kVAR
X Under Gen kVAR
X Over Gen kVAR
X Under Power kVA
X Over Power kVA
X Under PF Lagging
X Over PF Lagging
X Under PF Leading
X Over PF Leading
X Power Overflow
PW Warn Status
This parameter provides power based
warning identification as outlined in the
table below:
1 = Warning
0 = No Warning
Parameter Number 228
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-E4-01
Group Power Monitor
Units —
Minimum Value —
Maximum Value —
Default Value —
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Under Real Pwr
X Over Real Pwr
X Under Con kVAR
X Over Con kVAR
X Under Gen kVAR
X Over Gen kVAR
X Under Power kVA
X Over Power kVA
X Under PF Lagging
X Over PF Lagging
X Under PF Leading
X Over PF Leading
X Power Overflow
