Chapter 9 Trip History and Snapshot
Trip Snapshot Group
SS L1 Current
This parameter reports the value of L1
Current at the time of the last relay trip.
Parameter Number 144
Access Rule Get
Data Type INT
Object Mapping 0Fhex-90-01
Group Trip Snapshot
Units Amps
Minimum Value 0
Maximum Value 32767
Default Value —
SS L2 Current
This parameter reports the value of L2
Current at the time of the last relay trip.
Parameter Number 145
Access Rule Get
Data Type INT
Object Mapping 0Fhex-91-01
Group Trip Snapshot
Units Amps
Minimum Value 0
Maximum Value 32767
Default Value —
SS L3 Current
This parameter reports the value of L3
Current at the time of the last relay trip.
Parameter Number 146
Access Rule Get
Data Type INT
Object Mapping 0Fhex-92-01
Group Trip Snapshot
Units Amps
Minimum Value 0
Maximum Value 32767
Default Value —
SS %TCU
This parameter reports the value of
percent thermal capacity utilization at
the time of the last relay trip.
Parameter Number 147
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-93-01
Group Trip Snapshot
Units %
Minimum Value 0
Maximum Value 100
Default Value —
SS GF Current
This parameter reports the value of
ground fault current at the time of the
last relay trip.
Parameter Number 148
Access Rule Get
Data Type INT
Object Mapping 0Fhex-94-01
Group Trip Snapshot
Units Amps
Minimum Value 0
Maximum Value 1275
Default Value —
