Rockwell Automation Publication 193-UM002I-EN-P - December 2011 165
Power Parameters Chapter 8
kWh 10E0
This parameter provides a component of
total real energy (kWh). Multiply this
value by 10
0 and add to the other kWh
parameters.
Represents 000,000,XXX.000
Parameter Number 191
Access Rule Get
Data Type INT
Object Mapping 0Fhex-BF-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kWh 10E-3
This parameter provides a component of
total real energy (kWh). Multiply this
value by 10
-3 and add to the other kWh
parameters.
Represents 000,000,000.XXX
Parameter Number 192
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C0-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kVARh Con 10E6
This parameter provides a component of
total reactive energy consumed (kVARh).
Multiply this value by 10
6 and add to the
other kVARh consumed parameters.
Represents XXX,000,000.000
Parameter Number 193
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C1-01
Group Power Monitor
Units
Minimum Value -32768
Maximum Value 32767
Default Value —
kVARh Con 10E3
This parameter provides a component of
total reactive energy consumed (kVARh).
Multiply this value by 10
3 and add to the
other kVARh consumed parameters.
Represents 000,XXX,000.000
Parameter Number 194
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C2-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kVARh Con 10E0
This parameter provides a component of
total reactive energy consumed (kVARh).
Multiply this value by 10
0
and add to the
other kVARh consumed parameters.
Represents 000,000,XXX.000
Parameter Number 195
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C3-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
