176 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 8 Power Parameters
OVARG Inhibit Time
This parameter defines the amount of
time for which an over reactive power
(kVAR) generated detection is inhibited
during a motor starting sequence.
Parameter Number 261
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-105-01
Group Power Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
OVARG Trip Delay
This parameter allows the installer to
program a time duration for which an
over reactive power (kVAR) generated
condition must exist prior to the device
tripping.
Parameter Number 262
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-106-01
Group Power Setup
Units Seconds
Minimum Value 0.1
Maximum Value 25.0
Default Value 1.0
OVARG Trip Level
This parameter sets the over reactive
power (kVAR) generated trip level.
Parameter Number 263
Access Rule Get/Set
Data Type INT
Object Mapping 0Fhex-107-01
Group Power Setup
Units kVAR
Minimum Value -32768
Maximum Value 0
Default Value —
OVARG Warn Level
This parameter sets the over reactive
power (kVAR) generated warning level.
Parameter Number 264
Access Rule Get/Set
Data Type INT
Object Mapping 0Fhex-108-01
Group Power Setup
Units kVAR
Minimum Value -32768
Maximum Value 0
Default Value —
UVA Inhibit Time
This parameter defines the amount of
time for which an under apparent power
(kVA) detection is inhibited during a
motor starting sequence.
Parameter Number 265
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-109-01
Group Power Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
