246 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Appendix B DeviceNet™ Information
Parameter Group Instance names and member parameter instances for each
group are product specific. The following instance attributes will be supported
for all parameter group instances:
The following common services will be implemented for the Parameter Group
Object.
Discrete Output Group
Object - CLASS CODE
0x001E A single instance of the Discrete Output Group Object will be supported. All
instances will contain the following attributes.
The following common services will be implemented for the Discrete Input
Group Object.
Table 114 - Parameter Group Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instances UINT 7
8 Get
Native
Language
USINT 1 = English
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING
2 Get Number of Members UINT
3 Get 1 st Parameter UINT
4 Get 2 nd Parameter UINT
n Get Nth Parameter UINT
Service
Code Implemented for: Service
Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING
3 Get Number of Instances USINT 1 for E3, 2 for E3 Plus
4 Get Binding Array of UINT List of DOP instances
6 Get/Set Command BOOL 0=idle; 1=run
104 Get/Set Network Status Override BOOL
0=No Override (go to
safe state)
1=Override (run local
logic)
105 Get/Set Comm Status Override BOOL
0=No override (go to
safe state)
1=Override (run local
logic)
