Functionality specifications – Rockwell Automation 193-EC1_2_3_5, 193-ECPM,592-EC1_2_3_5 E3 and E3 Plus Solid-State Overload Relay User Manual User Manual
Page 228
228
Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Appendix A Specifications
➊Performance Criteria 1 requires the DUT to experience no degradation or loss of performance.
➋Environment 2.
Functionality
Specifications
Surge Immunity
Test Level:
Performance Criteria:
2kV (L-E)
1kV (L-L)
1 ➊➋
Radiated Emissions
Class A
Conducted Emissions
Class A
Table A.1 Electromagnetic Compatibility Specifications
Table 21: DeviceNet Communications
Baud Rate
125 k, 250 k, 500 k
Auto-Baud Rate Identification
Yes
“Group 2 – Slave Only” device type
Yes
Polled I/O Messaging
Yes
Change of State Messaging
Yes
Cyclic Messaging
Yes
Explicit Messaging
Yes
Full Parameter Object Support
Yes
Group 4 – Off-Line Node Recovery Messaging
Yes
Configuring Consistency Value
Yes
Unconnected Messaging Manager (UCMM)
Yes
