Appendix B DeviceNet™ Information
➊ 50…100% for devices with FRN 1.003 and earlier.
➋ FRN 2.000 and later.
➌ FRN 1.003 and earlier.
➍ FRN 3.001 and later.
The following common services are implemented for the Overload Object:
DPI Fault Object - CLASS
CODE 0x0097
This object provides access to fault information within the device. The following
class attributes will be supported:
Five instances of the DPI Fault Object will be supported.
195➋
229➌
Get
L3 Current Times
10
UINT
This attribute exists
only for current ranges
that report 2 decimal
place resolution
Current
Range
Dependent
196➋
230➌
Get
Avg Current Div
10
UINT
This attribute exists
only for current ranges
that report 0 decimal
place resolution
Current
Range
Dependent
197➋
231➌
Get
L1 Current Div 10
UINT
This attribute exists
only for current ranges
that report 0 decimal
place resolution
Current
Range
Dependent
198➋
232➌
Get
L2 Current Div 10
UINT
This attribute exists
only for current ranges
that report 0 decimal
place resolution
Current
Range
Dependent
199➋
233➌
Get
L3 Current Div 10
UINT
This attribute exists
only for current ranges
that report 0 decimal
place resolution
Current
Range
Dependent
Table 121 - Overload Object Common Services
Service
Code
Implemented for:
Service
Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x10
No
Yes
Set_Attribute_Single
Table 120 - Overload Object Instance Attributes
Attribute
ID
Access
Rule
Name
Data
Type
Value
Default
Table 122 - Fault Object Instance Attributes
Attribute ID
Access
Rule
Name
Data Type
Value
1
Get
Class Revision
UINT
1
2
Get
Number of Instances
UINT
5
3
Get/Set
Fault Cmd Write
USINT
0=NOP; 1=Clear Fault;
2=Clear Flt Queue
4
Get
Fault Instance Read
UINT
The instance of the Fault
Queue Entry containing
information about the Fault
that tripped the Device
6
Get
Number of Recorded
Faults
UINT
The number of Faults
recorded in the Fault Queue
