Rockwell Automation 193-EC1_2_3_5, 193-ECPM,592-EC1_2_3_5 E3 and E3 Plus Solid-State Overload Relay User Manual User Manual
Page 25

Rockwell Automation Publication 193-UM002I-EN-P - December 2011
25
Installation & Wiring Chapter 2
Figure 10 - 193-ECPM3 Panel Adapter for use with Cat. No. 193-EC_ _E
Figure 11 - Separate Panel Adapter for use with Cat. No. 193-EC_ _ F, G, & H
131.2
(5-11/64)
11.4
(29/64)
77
(3-1/32)
15
(19/32)
150.5
(5-15/16)
155.1
(6-7/64) w/
193-EIMD
130
(5-1/8)
71.7
(2-53/64)
60
(2-23/64)
5.0
(13/64)
Ø 5.5
(7/32)
K
0
2
4
6
8
0
2
4
6
8
M
N
P
A
D
B
C
E
F
E
L
J
G
I
H
Overload
Cat. No.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
193-EC_ _ F 4.72
(120.0)
7.19
(182.6)
6.09
(154.6)
3.94
(100)
1.54
(39)
0.45
(11.4)
1.03
(26.3)
5.32
(135)
1.94
(49.4)
0.22
(5.6)
0.24
(6.0)
0.47
(12)
5.95
(151.2)
6.89
(175)
7.12
(180.9)
193-EC_ _ G 6.09
(154.7)
7.40
(188.1)
6.41
(162.8)
5.12
(130)
1.89
(48)
0.45
(11.4)
1.06
(26.8)
5.51
(140.0)
2.03
(51.5)
0.26
(6.5)
0.08
(2.0)
0.49
(12.5)
6.89
(175)
7.83
(198.9)
8.06
(204.7)
193-EC_ _H 10.0
(255.0)
10.28
(261.0)
8.54
(217.0)
8.90
(226)
2.76
(70)
0.45
(11.4)
3.97
(100.8)
4.24
(107.7)
1.37
(134.9)
0.53
(13.5)
—
0.87
(22.0)
10.54
(267.8)
11.49
(291.7)
11.72
(297.5)
