Rockwell Automation 193-EC1_2_3_5, 193-ECPM,592-EC1_2_3_5 E3 and E3 Plus Solid-State Overload Relay User Manual User Manual
Page 140

140
Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 6 Monitoring Parameters
CURRENT IMBAL
This parameter provides the percent
current imbalance measurement.
%CI = 100 (I
d
/I
a
)
where,
CI: Current imbalance
I
d
: Maximum deviation from the average
current
I
a
: Average current
Parameter Number
11
Access Rule
Get
Data Type
USINT
Object Mapping
2C
hex
-1-111
Group
Monitor
Units
%
Minimum Value
0
Maximum Value
200
Default Value
None
TIME TO TRIP
This parameter provides an estimated
time for an overload trip to occur when
the measured motor current exceeds the
trip rating. When the measured current is
below the trip rating, the value 9,999
seconds is reported.
Parameter Number
12
Access Rule
Get
Data Type
UINT
Object Mapping
2C
hex
-1-112
Group
Monitor
Units
Seconds
Minimum Value
0
Maximum Value
9999
Default Value
9999
TIME TO RESET
This parameter reports the time until an
overload trip may be reset either manually
or automatically. After an overload trip is
reset, the value 9,999 seconds is reported.
Parameter Number
13
Access Rule
Get
Data Type
UINT
Object Mapping
2C
hex
-1-113
Group
Monitor
Units
Seconds
Minimum Value
0
Maximum Value
9999
Default Value
9999
