184 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 9 Trip History and Snapshot
Trip History 3
This parameter reports the trip written to
the Trip History previous to Trip History 2.
Refer to Table 8.1 for the Trip History
record identification.
Parameter Number 135
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-87-01
Group TripWarn History
Units —
Minimum Value 0
Maximum Value 48
Default Value —
Trip History 4
This parameter reports the trip written to
the Trip History previous to Trip History 3.
Refer to Table 8.1 for the Trip History
record identification.
Parameter Number 136
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-88-01
Group TripWarn History
Units —
Minimum Value 0
Maximum Value 48
Default Value —
Warn History 0
This parameter reports the latest
warning written to the Warning History.
Refer to Table 8.1 for the Warning History
record identification.
Parameter Number 137
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-89-01
Group TripWarn History
Units —
Minimum Value 0
Maximum Value 48
Default Value —
Warn History 1
This parameter reports the warning
written to the Warning History previous
to Warn History 0. Refer to Table 8.1 for
the Warning History record
identification.
Parameter Number 138
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-8A-01
Group TripWarn History
Units —
Minimum Value 0
Maximum Value 48
Default Value —
Warn History 2
This parameter reports the warning
written to the Warning History previous
to Warn History 1. Refer to Table 8.1 for
the Warning History record
identification.
Parameter Number 139
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-8B-01
Group TripWarn History
Units —
Minimum Value 0
Maximum Value 48
Default Value —
