Rockwell Automation 193-EC1_2_3_5, 193-ECPM,592-EC1_2_3_5 E3 and E3 Plus Solid-State Overload Relay User Manual User Manual
Page 157
Rockwell Automation Publication 193-UM002I-EN-P - December 2011
157
Voltage Parameters Chapter 7
PT Pri
This parameter sets the primary winding
value of the potential transformer being
used to step down a voltage signal that is
being measured.
Only used on the 193-EC5ZZ (9…5000 A)
Parameter Number
289
Access Rule
Get/Set
Data Type
UINT
Object Mapping
0Fhex-121-01
Group
Voltage Setup
Units
Volts
Minimum Value
1
Maximum Value
65535
Default Value
480
PT Sec
This parameter sets the secondary winding
value of the potential transformer being
used to step down a voltage signal that is
being measured.
Only used on the 193-EC5ZZ (9…5000 A)
Parameter Number
290
Access Rule
Get/Set
Data Type
UINT
Object Mapping
0Fhex-122-01
Group
Voltage Setup
Units
Volts
Minimum Value
1
Maximum Value
540
Default Value
480
