Rockwell Automation Publication 193-UM002I-EN-P - December 2011 21
Installation & Wiring Chapter 2
Approximate Dimensions
Approximate dimensions are shown in millimeters (inches). Dimensions are not
intended to be used for manufacturing purposes.
Figure 5 - Overload Relay 193-EC_ _ B, D, & E with Contactor 100-C*
C
A
H
F1
D2
ØD
D1
E1
B1
B
11.4
(29/64)
Cat. No.
Height B
193-EIMD
Overload
Relay Contactor
100- Width
A
without with B1
Depth
C
E1 F1 D1 D2 H Ø D
193-EC_ _B C09, C-12,
C16, C23
45
(1-25/32) 188.3
(7-13/32) 207.7
(8-11/64) 145.1
(5-23/32) 107
(4-7/32) 67.9
(2-43/64) 53.2
2-3/32) 60
(2-23/64) 35
(1-3/8) 85.1
(3-23/64) 4.2
(11/64)
193-EC_ _D C30, C37 104
(4-3/32)
C43 54
(2-1/8) 62.2
(2-7/16) 45
(1-25/32) 107
(4-7/32)
193-EC_ _E C60, C72,
C85
72
(2-53/64) 236.1
(9-19/64) 255.5
(10-1/16) 173.2
(6-13/16) 124.6
(4-29/32) 89.8
(3-17/32) 80.2
(3-9/64) 100
(3-15/16) 55
(2-11/64) 125.5
(4-15/16) 5.5
(7/32)
