166 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 8 Power Parameters
kVARh Con 10E-3
This parameter provides a component of
total reactive energy consumed (kVARh).
Multiply this value by 10
-3 and add to the
other kVARh consumed parameters.
Represents 000,000,000.XXX
Parameter Number 196
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C4-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kVARh Gen 10E6
This parameter provides a component of
total reactive energy generated (kVARh).
Multiply this value by 10
6 and add to the
other kVARh generated parameters.
Represents XXX,000,000.000
Parameter Number 197
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C5-01
Group Power Monitor
Units
Minimum Value -32768
Maximum Value 32767
Default Value —
kVARh Gen 10E3
This parameter provides a component of
total reactive energy generated (kVARh).
Multiply this value by 10
3 and add to the
other kVARh generated parameters.
Represents 000,XXX,000.000
Parameter Number 198
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C6-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kVARh Gen 10E0
This parameter provides a component of
total reactive energy generated (kVARh).
Multiply this value by 10
0 and add to the
other kVARh generated parameters.
Represents 000,000,XXX.000
Parameter Number 199
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C7-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
kVARh Gen 10E-3
This parameter provides a component of
total reactive energy generated (kVARh).
Multiply this value by 10
-3
and add to the
other kVARh generated parameters.
Represents 000,000,000.XXX
Parameter Number 200
Access Rule Get
Data Type INT
Object Mapping 0Fhex-C8-01
Group Power Monitor
Units
Minimum Value -999
Maximum Value 999
Default Value —
