174 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 8 Power Parameters
UVARC Trip Level
This parameter sets the under reactive
power (kVAR) consumed trip level.
Parameter Number 251
Access Rule Get/Set
Data Type INT
Object Mapping 0Fhex-FB-01
Group Power Setup
Units kVAR
Minimum Value 0
Maximum Value 32767
Default Value —
UVARC Warn Level
This parameter sets the under reactive
power (kVAR) consumed warning level.
Parameter Number 252
Access Rule Get/Set
Data Type INT
Object Mapping 0Fhex-FC-01
Group Power Setup
Units kVAR
Minimum Value 0
Maximum Value 32767
Default Value —
OVARC Inhibit Time
This parameter defines the amount of
time for which an over reactive power
(kVAR) consumed detection is inhibited
during a motor starting sequence.
Parameter Number 253
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-FD-01
Group Power Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
OVARC Trip Delay
This parameter allows the installer to
program a time duration for which an
over reactive power (kVAR) consumed
condition must exist prior to the device
tripping.
Parameter Number 254
Access Rule Get/Set
Data Type USINT
Object Mapping 0Fhex-FE-01
Group Power Setup
Units Seconds
Minimum Value 0.1
Maximum Value 25.0
Default Value 1.0
OVARC Trip Level
This parameter sets the over reactive
power (kVAR) consumed trip level.
Parameter Number 255
Access Rule Get/Set
Data Type INT
Object Mapping 0Fhex-FF-01
Group Power Setup
Units kVAR
Minimum Value 0
Maximum Value 32767
Default Value —
