124

Rockwell Automation Publication 193-UM002I-EN-P - December 2011

Chapter 5 Programmable Parameters

Table 60 - Other Reset/Test Lock Group Parameters Detail

RESET MAX kVA DMND

This parameter allows the installer to reset

the maximum kVA Demand parameter to

zero.

Parameter Number

298

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

0Fhex-12A-01

Group

Reset/Lock

Units

Minimum Value

0 = No Action

Maximum Value

1 = Reset

Default Value

0

TRIP RESET

This parameter provides the user with the

capability of resetting a trip over the

DeviceNet network. After a trip is reset, the

parameter automatically returns to a

“Ready” state.

Parameter Number

26

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

0x29-1-126

Group

Reset/Lock

Units

Minimum Value

0 = Ready

Maximum Value

1 = Reset

Default Value

0

PROGRAM LOCK

This parameter prohibits the device

parameters from being altered when set to

“Locked”.

This parameter must be set to “Unlocked”

to allow parameter modification.

Parameter Number

53

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

0xB4-1-18

Group

Reset/Lock

Units

Minimum Value

0 = Unlocked

Maximum Value

1 = Locked

Default Value

0

SET TO DEFAULTS

This parameter allows the user to reset the

parameter settings to the factory default

values. After parameter values have been

reset to the factory default settings, the

parameter automatically returns to a

“Ready” state.

Parameter Number

54

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

0xB4-1-19

Group

Reset/Lock

Units

Minimum Value

0 = Ready

Maximum Value

1 = Set

Default Value

0

TEST ENABLE (Series C and later)

This parameter allows the installer to

enable or disable the test function of the

Test/Reset button.

Parameter Number

103

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

29hex-1-108

Group

Reset/Lock

Units

Minimum Value

0 = Disable

Maximum Value

1 = Enable

Default Value

1
