Rockwell Automation Publication 193-UM002I-EN-P - December 2011 249
DeviceNet™ Information Appendix B
➊ E3 Plus Models EC2 and EC3
E3 Plus Model EC5
The following common services are implemented for the Control Supervisor
Object:
124 Get/Set Trip Enable WORD
Bit 0 = Reserved
Bit 1 = Overload
Bit 2 = Phase Loss
Bit 3 = Ground Fault ➊
Bit 4 = Stall
Bit 5 = Jam
Bit 6 = Underload
Bit 7 = PTC ➊
Bit 8 = Current Imbal
Bit 9 = Comm Fault
Bit 10 = Comm Idle
Bit 11 = Reserved
Bit 12 = Reserved
Bit 13 = Reserved
Bit 14 = Remote Trip
Bit 15 = Start Inhibit
125 Get/Set Warning Enable WORD
Bit 0 = Reserved
Bit 1 = Overload
Bit 2 = Phase Loss
Bit 3 = Ground Fault ➊
Bit 4 = Stall
Bit 5 = Jam
Bit 6 = Underload
Bit 7 = PTC ➊
Bit 8 = Current Imbal
Bit 9 = Comm Fault
Bit 10 = Comm Idle
Bit 11 = Reserved
Bit 12 = Device Config
Bit 13 = PM Starts
Bit 14 = PM Oper Hours
126 Get/Set Trip Reset BOOL
0->1 = Trip Reset
otherwise no action
130 Get/Set Reset Mode BOOL
0 = Manual
1 = Automatic
131 Get/Set OL Reset Level USINT %FLA
132 Get/Set Clear Queues BOOL
0->1 = Clear fault and warning
queues, start counters and operating
hour accumulators
otherwise no action
177 Get/Set IN1 Assignment USINT
0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2 Speed
178 Get/Set IN2 Assignment USINT
0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2 Speed
179 Get/Set IN3 Assignment USINT
0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2 Speed
180 Get/Set IN4 Assignment USINT
0 = Normal
1 = Trip Reset
2 = Remote Trip
3 = 2 Speed
Table 115 - Control Supervisor Object Instance Attributes
Attribute
ID Access
Rule Name Data
Type Value
