128

Rockwell Automation Publication 193-UM002I-EN-P - December 2011

Chapter 5 Programmable Parameters

E3 is Tripped

In the event of a protection trip, the state of an E3 Overload Relay output is
determined by the programmed settings of the corresponding Out_ Pr FltState
and Out_ Pr FltValue parameters.

When Out_ Pr FltState is set to “Ignore Fault”, output operation continues to
respond to message commands. When Out_ Pr FltState is set to “Go to FltValue”,
the output commanded states are determined by the settings of the Out_ Pr
FltValue parameters, regardless of the state of the firmware latch.

Series A product continues to update the firmware latch as new commands are
received while the E3 Overload Relay is in a tripped state.

Series B and later product sets the firmware latch to the Out_ Pr FltValue when
Out_ Pr FltState is set to “Go to FltValue” while the E3 Overload Relay is in a
tripped state.

E3 is Reset from Trip

After an E3 Overload Relay is returned to normal following a trip reset, operation
of Out A and Out B is determined by the state of the firmware latch. The output
state matrix below details this.

Table 64 - Output State Matrix for Output Setup Parameters

Out X

Output State

Commanded

Output State
Prior to Trip

PR FltState

Setting

PR FltValue

Setting

with

Active

Trip

Last

Commanded

During Trip

Following Trip Reset

(before any new command)

Series A Series B & Later

Open

0 = Go to FltValue 0 = Open

Open

Open

Open

Open

Close

Closed

Open

-none -

Open

Open

1 = Closed

Closed

Open

Open

Closed

Close

Closed

Closed

-none -

Open

Closed

1 = Ignore Fault

As Commanded

Close

0 = Go to FltValue 0 = Open

Open

Open

Open

Open

Close

Closed

Open

-none -

Closed

Open

1 = Closed

Closed

Open

Open

Closed

Close

Closed

Closed

-none -

Closed

Closed

1 = Ignore Fault

As Commanded
