132 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 5 Programmable Parameters
Table 68 - Net Outputs Parameter Detail
Table 69 - Net Outputs Bit Function Detail
Table 70 - Net Outputs Change-of-State (COS) Mask Parameter Detail
NET OUTPUTS
This parameter monitors network outputs
controlled through DeviceLogix programs.
Parameter Number 81
Access Rule Get/Set
Data Type WORD
Object Mapping 0x04-1-3
Group DeviceLogix
Units —
Minimum Value
Maximum Value
Default Value
Bits
Function 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Net Output 0
X Net Output 1
X Net Output 2
X Net Output 3
X Net Output 4
X Net Output 5
X Net Output 6
X Net Output 7
X Net Output 8
X Net Output 9
X Net Output 10
X Net Output 11
X Net Output 12
X Net Output 13
X Net Output 14
X DLogix Enabled
NET OUT COS MASK
This parameter allows the installer to select
the events for which a COS message is
produced.
1 = Enabled
0 = Disabled
Parameter Number 82
Access Rule Get/Set
Data Type WORD
Object Mapping 0xB4-1-50
Group DeviceLogix
Units —
Minimum Value
Maximum Value
Default Value
