Chapter 9 Trip History and Snapshot
V TripHist Mask
This parameter allows the user to
configure which voltage based
protection features are written to the five
record Trip History as outlined in the
table below:
1 = Recorded
0 = Not Recorded
Parameter Number
299
Access Rule
Get/Set
Data Type
UINT
Object Mapping
0Fhex-12B-01
Group
TripWarn History
Units
—
Minimum Value
0000000000000000
Maximum Value
0000000001111111
Default Value
0000000001111111
Bit
Function:
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
X
Voltage Hdwr Flt
X
Under Volt L-L
X
Over Volt L-L
X
Voltage Unbal
X
Phase Rotation
X
Under Frequency
X
Over Frequency
V WarnHist Mask
This parameter allows the user to
configure which voltage based
protection features are written to the five
record Warning History as outlined in the
table below:
1 = Recorded
0 = Not Recorded
Parameter Number
300
Access Rule
Get/Set
Data Type
UINT
Object Mapping
0Fhex-12C-01
Group
TripWarn History
Units
—
Minimum Value
0000000000000000
Maximum Value
0000000001111111
Default Value
0000000001111111
Bit
Function:
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
X
Voltage Hdwr Flt
X
Under Volt L-L
X
Over Volt L-L
X
Voltage Unbal
X
Phase Rotation
X
Under Frequency
X
Over Frequency
PW TripHist Mask
This parameter allows the user to
configure which power based protection
features are written to the five record Trip
History as outlined in the table below:
1 = Recorded
0 = Not Recorded
Parameter Number
301
Access Rule
Get/Set
Data Type
UINT
Object Mapping
0Fhex-12D-01
Group
TripWarn History
Units
—
Minimum Value
0000000000000000
Maximum Value
0001111111111111
Default Value
0001111111111111
