130 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 5 Programmable Parameters
Table 66 - Output B Parameters Detail — E3 Plus
OUTA DN IDLVALUE
This parameter determines the state that
Output A assumes when the network is idle
and Parameter 69 is set to “0”.
Parameter Number 70
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-8
Group Advanced Setup
Units —
Minimum Value 0 = Open
Maximum Value 1 = Closed
Default Value 0
OUTB PR FLTSTATE
This parameter, in conjunction with
Parameter 72, defines how Output B will
respond when a trip occurs. When set to
“1”, Output B will continue to operate as
commanded via the network. When set to
“0”, Output B will open or close as
determined by the setting in Parameter 72.
Parameter Number 71
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-2-113
Group DeviceNet I/O
Units —
Minimum Value 0 = Go to FltValue (#72)
Maximum Value 1 = Ignore Fault
Default Value 0
OUTB PR FLTVALUE
This parameter determines the state that
Output B assumes when a trip occurs and
Parameter 71 is set to “0”.
Parameter Number 72
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-2-114
Group DeviceNet I/O
Units —
Minimum Value 0 = Open
Maximum Value 1 = Closed
Default Value 0
OUTB DN FLTSTATE
This parameter, in conjunction with
Parameter 74, defines how Output B will
respond when a DeviceNet network fault
occurs. When set to “1”, Output B will hold
the state prior to trip occurrence. When set
to “0”, Output B will open or close as
determined by the setting in Parameter 74.
Output B can be configured to go to a
desired state in the event of a DeviceNet
network fault independent from enabling
CommFault in Parameter 24, Trip Enable.
Parameter Number 73
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-2-5
Group DeviceNet I/O
Units —
Minimum Value 0 = Go to FltValue (#74)
Maximum Value 1 = Hold Last State
Default Value 0
OUTB DN FLTVALUE
This parameter determines the state that
Output B assumes when a comm fault
occurs and Parameter 73 is set to “0”.
Parameter Number 74
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-2-6
Group DeviceNet I/O
Units —
Minimum Value 0 = Open
Maximum Value 1 = Closed
Default Value 0
