Rockwell Automation Publication 193-UM002I-EN-P - December 2011 163
Power Parameters Chapter 8
L1 Apparent Pwr
This parameter provides the apparent
power (kVA) measured in L1 with
measurement in kiloVolt-Amperes.
Parameter Number 181
Access Rule Get
Data Type INT
Object Mapping 0Fhex-B5-01
Group Power Monitor
Units kVA
Minimum Value -32768
Maximum Value 32767
Default Value —
L2 Apparent Pwr
This parameter provides the apparent
power (kVA) measured in L2 with
measurement in kiloVolt-Amperes.
Parameter Number 182
Access Rule Get
Data Type INT
Object Mapping 0Fhex-B6-01
Group Power Monitor
Units kVA
Minimum Value -32768
Maximum Value 32767
Default Value —
L3 Apparent Pwr
This parameter provides the apparent
power (kVA) measured in L3 with
measurement in kiloVolt-Amperes.
Parameter Number 183
Access Rule Get
Data Type INT
Object Mapping 0Fhex-B7-01
Group Power Monitor
Units kVA
Minimum Value -32768
Maximum Value 32767
Default Value —
Tot Apparent Pwr
This parameter provides the total
apparent power (kVA) measured in all
phases with measurement in
kiloVolt-Amperes.
Parameter Number 184
Access Rule Get
Data Type INT
Object Mapping 0Fhex-B8-01
Group Power Monitor
Units kVA
Minimum Value -32768
Maximum Value 32767
Default Value —
L1 PF
This parameter provides the power factor
measured in L1 with measurement in
percentage.
Parameter Number 185
Access Rule Get
Data Type SINT
Object Mapping 0Fhex-B9-01
Group Power Monitor
Units %
Minimum Value -100
Maximum Value 100
Default Value —
