Trip History and Snapshot Chapter 9
SS L1-L2 Voltage
This parameter reports the value of L1-L2
voltage at the time of the last relay trip
(only in the E3 Plus model EC5).
Parameter Number 149
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-95-01
Group Trip Snapshot
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value —
SS L2-L3 Voltage
This parameter reports the value of L2-L3
voltage at the time of the last relay trip
(only in the E3 Plus model EC5).
Parameter Number 150
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-96-01
Group Trip Snapshot
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value —
SS L3-L1 Voltage
This parameter reports the value of L3-L1
voltage at the time of the last relay trip
(only in the E3 Plus model EC5).
Parameter Number 151
Access Rule Get
Data Type UINT
Object Mapping 0Fhex-97-01
Group Trip Snapshot
Units Volts
Minimum Value 0
Maximum Value 65535
Default Value —
SS Tot Real Pwr
This parameter reports the value of total
real power (kW) at the time of the last
relay trip (only in the E3 Plus model EC5).
Parameter Number 152
Access Rule Get
Data Type INT
Object Mapping 0Fhex-98-01
Group Trip Snapshot
Units kW
Minimum Value -32768
Maximum Value 32767
Default Value —
SS Tot kVAR
This parameter reports the value of total
reactive power (kVAR) at the time of the
last relay trip (only in the E3 Plus model
EC5).
Parameter Number 153
Access Rule Get
Data Type INT
Object Mapping 0Fhex-99-01
Group Trip Snapshot
Units kVAR
Minimum Value -32768
Maximum Value 32767
Default Value —
