Rockwell Automation Publication 193-UM002I-EN-P - December 2011 129
Programmable Parameters Chapter 5
Table 65 - Output A Parameters Detail
OUTA PR FLTSTATE
This parameter, in conjunction with
Parameter 66, defines how Output A will
respond when a trip occurs. When set to
“1”, Output A will continue to operate as
commanded via the network. When set to
“0”, Output A will open or close as
determined by the setting of Parameter 66.
Parameter Number 65
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-113
Group DeviceNet I/O
Units —
Minimum Value 0 = Go to FltValue (#66)
Maximum Value 1 = Ignore Fault
Default Value 0
OUTA PR FLTVALUE
This parameter determines the state that
Output A assumes when a trip occurs and
Parameter 65 is set to “0”.
Parameter Number 66
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-114
Group DeviceNet I/O
Units —
Minimum Value 0 = Open
Maximum Value 1 = Closed
Default Value 0
OUTA DN FLTSTATE
This parameter, in conjunction with
Parameter 68, defines how Output A will
respond when a DeviceNet network fault
occurs. When set to “1”, Output A will hold
the state prior to trip occurrence. When set
to “0”, Output A will open or close as
determined by the setting of Parameter 68.
Output A can be configured to go to a
desired state in the event of a DeviceNet
network fault independent from enabling
CommFault in Parameter 24, Trip Enable.
Parameter Number 67
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-5
Group DeviceNet I/O
Units —
Minimum Value 0 = Go to FltValue (#68)
Maximum Value 1 = Hold Last State
Default Value 0
OUTA DN FLTVALUE
This parameter determines the state that
Output A assumes when a DeviceNet
network fault occurs and Parameter 67 is
set to “0”.
Parameter Number 68
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-6
Group DeviceNet I/O
Units —
Minimum Value 0 = Open
Maximum Value 1 = Closed
Default Value 0
OUTA DN IDLSTATE
This parameter, in conjunction with
Parameter 70, defines how Output A will
respond when the DeviceNet network is
idle. When set to “1”, Output A will hold
the state prior to trip occurrence. When set
to “0”, Output A will open or close as
determined by the setting in Parameter 70.
The Dn Flt parameters supersede the Dn Idl
parameters.
Parameter Number 69
Access Rule Get/Set
Data Type BOOL
Object Mapping 0x09-1-7
Group DeviceNet I/O
Units —
Minimum Value 0 = Go to IdlValue (#70)
Maximum Value 1 = Hold Last State
Default Value 0
