Installation & Wiring Chapter 2
High-Fault Short-Circuit Ratings
Table 12 - Per UL 508 & CSA 22.2, No. 14 with Bulletin 100-C & 100-D Contactors
Cat. No.
193-EC1, -EC2, -EC3,
-EC4, -EC5
Maximum
Contactor
100- Starter
FLC [A] Available Fault
Current [A]
Voltage [V]
Class J or
CC Fuse [A]
_B C09 9 100,000 600 20
C12 12 20
C16 16 30
C23 23 30
_D C30 30 100,000 600 50
C37 37 50
C43 43 70
_E C60 60 100,000 600 80
C72 72 100
C85 85 150
FF, ZZ D95 95 100,000 600 200
D110 110 200
D140 140 250
GF, ZZ D180 180 100,000 600 300
GG, ZZ D210 210 100,000 600 400
D250 250 400
D300 300 500
HG, ZZ D210 210 100,000 600 400
D250 250 400
D300 300 500
JG, ZZ D300 300 100,000 600 500
D420 420 600
