Chapter 6 Monitoring Parameters
➊ Series C and later
WARNING STATUS
This parameter provides warning
identification.
Parameter Number 15
Access Rule Get
Data Type WORD
Object Mapping 0x29-1-115
Group Monitor
Units —
Minimum Value —
Maximum Value —
Default Value None
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
—
X Overload
—
X Ground Fault (E3 Plus)
—
X Jam
X Underload
X PTC (E3 Plus)
X Current Imbalance
X Comm Fault
X Comm Idle
—
X Config Fault
X PM - # Starts ➊
X PM – Oper. Hours ➊
TRIP LOG 0
This parameter records the latest trip.
Parameter Number 16
Access Rule Get
Data Type WORD
Object Mapping 0x29-1-116
Group Monitor
Units —
Minimum Value See Trip Status table
Maximum Value See Trip Status table
Default Value None
TRIP LOG 1
This parameter records the trip previous to
Trip Log 0.
Parameter Number 17
Access Rule Get
Data Type WORD
Object Mapping 0x29-1-117
Group Monitor
Units —
Minimum Value See Trip Status table
Maximum Value See Trip Status table
Default Value None
