154

Rockwell Automation Publication 193-UM002I-EN-P - December 2011

Chapter 7 Voltage Parameters

OV Warn Level

This parameter sets the over voltage
warning level.

Parameter Number

222

Access Rule

Get/Set

Data Type

UINT

Object Mapping

0Fhex-DE-01

Group

Voltage Setup

Units

Volts

Minimum Value

0

Maximum Value

65535

Default Value

490

Ph Rot Inhibit Time

This parameter defines the amount of time
for which an improper phase rotation
detection is inhibited during a motor
starting sequence.

Parameter Number

223

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-DF-01

Group

Voltage Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

10

Ph Rot Trip

This parameter sets the rotation trip and
warning direction.

Parameter Number

224

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-E0-01

Group

Voltage Setup

Units

1 = ABC
2 = ACB

Minimum Value

1

Maximum Value

2

Default Value

1

V UnbalInhib Time

This parameter defines the amount of time
for which voltage unbalance detection is
inhibited during a motor starting
sequence.

Parameter Number

229

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-E5-01

Group

Voltage Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

10

V UnbalTripDelay

This parameter allows the installer to
program a time duration for which a
voltage unbalance condition must exist
prior to the device tripping.

Parameter Number

230

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-E6-01

Group

Voltage Setup

Units

Seconds

Minimum Value

0.1

Maximum Value

25.0

Default Value

1.0
