Chapter 12 Troubleshooting

of this chapter for tips associated with troubleshooting trip and warning
conditions.

Table 9: Trip/Warn Codes

➊ Series C and later

E3 Plus Model EC5 Only

Trip / Warning Description

Trip Table
(Long Red)

Trip Code
(Short Red)

Warning Table
(Long Amber)

Warning Code
(Short Amber)

Protection
Fault

Non-Volatile
Fault

Test Trip

1

No

No

Overload

2

2

Yes

Yes

Phase Loss

3

Yes

Yes

Ground Fault

4

4

Yes

Yes

Stall

5

Yes

Yes

Jam

6

6

Yes

Yes

Underload

7

7

Yes

Yes

PTC

8

8

Yes

Yes

Current Imbalance

9

9

Yes

Yes

Comm Fault

10

10

Yes

No

Comm Idle

11

11

Yes

No

NonVol Memory Fault

12

No

No

Hardware Fault

13

No

No

ConfigurationFault

13

No

No

PM - # Starts

14

No

No

Remote Trip

15

No

No

PM Oper. Hours

15

No

No

Blocked Start/Start Inhibit

16

No

No

Voltage Input Module Hardware Fault

1

1

1

1

No

No

Under Voltage L-L

1

2

1

2

Yes

Yes

Over Voltage L-L

1

3

1

3

Yes

Yes

Voltage Unbalance

1

4

1

4

Yes

Yes

Phase Rotation

1

5

1

5

Yes

Yes

Under Frequency

1

6

1

6

Yes

Yes

Over Frequency

1

7

1

7

Yes

Yes

Under Real Power (kW)

2

1

2

1

Yes

Yes

Over Real Power (kW)

2

2

2

2

Yes

Yes

Under Reactive Power Consumed (+kVAR)

2

3

2

3

Yes

Yes

Over Reactive Power Consumed (+kVAR)

2

4

2

4

Yes

Yes

Under Reactive Power Generated (-kVAR)

2

5

2

5

Yes

Yes

Over Reactive Power Generated (-kVAR)

2

6

2

6

Yes

Yes

Under Apparent Power (kVA)

2

7

2

7

Yes

Yes

Over Apparent Power (kVA)

2

8

2

8

Yes

Yes

Under Power Factor Lagging (-PF)

2

9

2

9

Yes

Yes

Over Power Factor Lagging (-PF)

2

10

2

10

Yes

Yes

Under Power Factor Leading (+PF)

2

11

2

11

Yes

Yes

Over Power Factor Leading (+PF)

2

12

2

12

Yes

Yes

Power Value Overflow (kW, kVAR or KVA)

2

13

2

13

Yes

Yes

IMPORTANT

The Trip conditions identified as “Protection Faults” are the
basis for the OUTA Pr FltState, OUTA Pr FltValue, OUTB Pr
FltState, and OUTB Pr FltValue parameters.
