Rockwell Automation Publication 193-UM002I-EN-P - December 2011

113

Programmable Parameters Chapter 5

Table 42 - Other Overload Setup Group Parameters Detail

TRIP CLASS

The value in this parameter determines the

maximum time (in seconds) for an overload

trip to occur when the motor operating

current is six times its rated current.

Parameter Number

29

Access Rule

Get/Set

Data Type

USINT

Object Mapping

2C

hex

-1-129

Group

Overload Setup

Units

Minimum Value

5

Maximum Value

30

Default Value

10

OL/PTC RESET MODE

This parameter defines whether an

Overload or PTC Trip can be automatically

or manually reset. Note: all other trips must

be manually reset.

Parameter Number

30

Access Rule

Get/Set

Data Type

BOOL

Object Mapping

0x29-1-130

Group

Overload Setup

Units

Minimum Value

0 = Manual

Maximum Value

1 = Auto

Default Value

0

OL RESET LEVEL

The value in this parameter establishes

what the value stored in Parameter 9, %

Therm Utilized, must fall below before an

overload trip can be manually or

automatically reset.

Parameter Number

31

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0x29-1-131

Group

Overload Setup

Units

% (Thermal Utilization)

Minimum Value

0

Maximum Value

100

Default Value

75

CT RATIO

This parameter defines the turns ratio of

the primary current transformers (when

used). See Table 41 - on page 5-112 for the

corresponding FLA setting ranges.

Parameter Number

78

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0x2-1-178

Group

Overload Setup

Units

Minimum Value

0 = 50:5
1 = 100:5
2 = 150:5
3 = 200:5
4 = 300:5
5 = 500:5
6 = 600:5
7 = 800:5
8 = 1200:5
9 = 2500:5

Maximum Value

10 = 5000:5

Default Value

0 = 50:5

FRN 2.000 and later
