Power Parameters Chapter 8
Power Setup Group
PW Trip Enable
This parameter allows the installer to
enable or disable power based trip
functions separately.
1 = Trip
0 = No TrIp
Parameter Number 225
Access Rule Get/Set
Data Type UINT
Object Mapping 0Fhex-E1-01
Group Power Setup
Units —
Minimum Value —
Maximum Value —
Default Value —
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Under Real Pwr
X Over Real Pwr
X Under Con kVAR
X Over Con kVAR
X Under Gen kVAR
X Over Gen kVAR
X Under Power kVA
X Over Power kVA
X Under PF Lagging
X Over PF Lagging
X Under PF Leading
X Over PF Leading
X Power Overflow
PW Warn Enable
This parameter allows the installer to
enable or disable power based warning
functions separately.
1 = Warning
0 = No Warning
Parameter Number 226
Access Rule Get/Set
Data Type UINT
Object Mapping 0Fhex-E2-01
Group Power Setup
Units —
Minimum Value —
Maximum Value —
Default Value —
Bit Function:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
X Under Real Pwr
X Over Real Pwr
X Under Con kVAR
X Over Con kVAR
X Under Gen kVAR
X Over Gen kVAR
X Under Power kVA
X Over Power kVA
X Under PF Lagging
X Over PF Lagging
X Under PF Leading
X Over PF Leading
X Power Overflow
