Installation & Wiring Chapter 2
Table 14 - IEC per EN60947-4-1
Table 15 - NEMA Contactors
Cat. No. 193-
EC1, EC2,
EC3, EC4, EC5
Contactor
100-
Max.
Starter
FLC [A]
Short-Circuit Current
Max.
Voltage
[V]
Class J Fuse [A]
Prospective
I
r
[A]
Conditional
I
q
[A]
with
Type I
with
Type II
_B C09 9 1,000 100,000 600 20 15
C12 12 20 20
C16 16 30 30
C23 23 40 40
_D C30 30 3,000 100,000 600 50 50
C37 37 50 50
C43 43 70 70
_E C60 60 3,000 100,000 600 80 80
C72 72 100 100
C85 85 5,000 150 150
FF, ZZ D95 95 10,000 100,000 600 200 200
D110 110 200 200
D140 140 250 250
GF, ZZ D180 180 10,000 100,000 600 300 300
GG, ZZ D210 210 10,000 100,000 600 400 400
D250 250 400 400
D300 300 500 500
HG, ZZ D210 210 10,000 100,000 600 400 400
D250 250 400 400
D300 300 500 500
JG, ZZ D300 300 10,000 100,000 600 500 500
D420 420 600 600
Cat. No.
592-EC
Contactor
Size
Max.
Starter
FLC [A]
Short-Circuit Current
Max.
Voltage
[V]
Class J Fuse [A]
Prospective
I
r
[A]
Conditional
I
q
[A]
with
Type I
with
Type II
_T 00 9 1,000 100,000 600 20 20
_C 0, 1 18, 27 3,000 30 30
2 45 60 60
_D 3 90 5,000 200 200
