118 Rockwell Automation Publication 193-UM002I-EN-P - December 2011
Chapter 5 Programmable Parameters
Table 52 - Stall Parameters Detail
Table 53 - Jam Parameters Detail
STALL ENABLED TIME
This parameter defines the amount of time
for which stall detection is enabled during
a motor starting sequence.
Parameter Number 39
Access Rule Get/Set
Data Type USINT
Object Mapping 2C
hex
-1-139
Group Advanced Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
STALL TRIP LEVEL
This parameter sets the stall trip level.
Parameter Number 40
Access Rule Get/Set
Data Type USINT
Object Mapping 2C
hex
-1-140
Group Advanced Setup
Units % FLA
Minimum Value 100
Maximum Value 600
Default Value 600
JAM INHIBIT TIME
This parameter defines the amount of time
for which jam detection is inhibited during
a motor starting sequence.
Parameter Number 41
Access Rule Get/Set
Data Type USINT
Object Mapping 2C
hex
-1-141
Group Advanced Setup
Units Seconds
Minimum Value 0
Maximum Value 250
Default Value 10
JAM TRIP DELAY
This parameter allows the installer to
program a time duration for which a jam
condition must exist at the programmed
level prior to the device tripping.
Parameter Number 42
Access Rule Get/Set
Data Type USINT
Object Mapping 2C
hex
-1-142
Group Advanced Setup
Units Seconds
Minimum Value 0.1
Maximum Value 25.0
Default Value 5.0
JAM TRIP LEVEL
This parameter sets the jam trip level.
Parameter Number 43
Access Rule Get/Set
Data Type UINT
Object Mapping 2C
hex
-1-143
Group Advanced Setup
Units % FLA
Minimum Value 50
Maximum Value 600
Default Value 250
