Rockwell Automation Publication 193-UM002I-EN-P - December 2011

173

Power Parameters Chapter 8

OW Trip Delay

This parameter allows the installer to
program a time duration for which an
over real power (kW) condition must
exist prior to the device tripping.

Parameter Number

246

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-F6-01

Group

Power Setup

Units

Seconds

Minimum Value

0.1

Maximum Value

25.0

Default Value

1.0

OW Trip Level

This parameter sets the over real power
(kW) trip level.

Parameter Number

247

Access Rule

Get/Set

Data Type

INT

Object Mapping

0Fhex-F7-01

Group

Power Setup

Units

kW

Minimum Value

0

Maximum Value

32767

Default Value

OW Warn Level

This parameter sets the over real power
(kW) warning level.

Parameter Number

248

Access Rule

Get/Set

Data Type

INT

Object Mapping

0Fhex-F8-01

Group

Power Setup

Units

kW

Minimum Value

0

Maximum Value

32767

Default Value

UVARC Inhibit Time

This parameter defines the amount of
time for which an under reactive power
(kVAR) consumed detection is inhibited
during a motor starting sequence.

Parameter Number

249

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-F9-01

Group

Power Setup

Units

Seconds

Minimum Value

0

Maximum Value

250

Default Value

10

UVARC Trip Delay

This parameter allows the installer to
program a time duration for which an
under reactive power (kVAR) consumed
condition must exist prior to the device
tripping.

Parameter Number

250

Access Rule

Get/Set

Data Type

USINT

Object Mapping

0Fhex-FA-01

Group

Power Setup

Units

Seconds

Minimum Value

0.1

Maximum Value

25.0

Default Value

1.0
